One connector compatible with OptiTap (Huawei/Furukawa), Slim, and Fastconnect Mini SC (Corning) ports. Reduce inventory cost by 60% while ensuring full network compatibility.Hardened outdoor connector designed for last-mile FTTH and aerial deployments. Direct interoperability with leading OEM systems. Compact slim connector ideal for high-density distribution boxes and tight enclosures where space is limited.Pre-polished mini SC connector for fast field installation. Industry-standard interface widely deployed in America.The Alteoptic 3×1 universal connector features a robust IP68-rated housing, precision ceramic ferrule, and reinforced strain-relief boot. Each unit is factory-terminated and tested to ensure consistent insertion loss across thousands of mating cycles.
The 3-In-1 waterproof fiber optic connector is a structural evolution from the Furukawa Type. This is our second-generation design (the first generation with metal connector tabs is now discontinued) and is known as a "translator" in the Brazilian market. By replacing the adapter, it can achieve free conversion between Huawei and Corning connectors; It is easy to operate and has minimal data changes after conversion.
The 3-In-1 waterproof fiber optic connectors feature a special plastic shell highly resistant to temperature extremes, acid and alkaline corrosion, UV rays, and water exposure. The construction is strong and supported by waterproof rubber seals, giving an IP68 waterproof rating. These connectors are compatible with fiber optic waterproof ports from manufacturers such as Corning, Huawei, and Furukawa. They can be used in various fiber optic network configurations, including 3.0mm-5.0mm single-core circular cables and FTTH leather fiber cables for home installations.
The IP68 waterproof rating provides full protection against dust and long immersion in water, making these connectors highly suitable for outdoor and especially industrial applications.
These connectors are designed to be fully compatible with larger fiber optic systems including those made by Corning, Huawei, and Furukawa, thus guaranteeing a trouble-free integration into various systems.
Made from materials that conform to RoHS (Restriction of Hazardous Substances) and RE-Coat (Registration, Evaluation, Authorization and Restriction of Chemicals), these connectors conform to modern global environmental regulations.
These connectors are manufactured to UL94-V0 fire rating standards and can be safely used in places where fire resistance is required.
This waterproof fiber optic connector can be used with 3.0mm and 5.0mm round cables and also 2*5mm broad drop cables, allowing for flexible installation across a variety of network configurations.
Furukawa Waterproof Fiber Optic Connector
Huawei Waterproof Fiber Optic Connector
Corning Waterproof Fiber Optic Connector
Technical Parameters of Waterproof Fiber Optic Connectors
|
Parameter |
Specification |
|
Insertion Loss |
≤ 0.3dB |
|
Return Loss |
≥ 55dB |
|
Tensile Strength for 3.0mm Round Cable |
> 90N |
|
Tensile Strength for 5.0mm Round Cable |
> 200N |
|
Tensile Strength for 2.0*5.0mm Drop Cable |
> 150N |
|
Operating Temperature |
-40°C to +85°C |
|
Storage Temperature |
-35°C to +75°C |
|
Protection Level |
IP68 |
Packing Details
|
Item |
SC/APC Waterproof Fiber Optic Connector |
|
Size |
29cm * 25cm * 25cm |
|
Quantity per Box |
100 sets |
|
Gross Weight per Box |
6kg |
|
Net Weight per Box |
5.5kg |
