Fiber optic adapters normally comes with metal or plastic housings, there are types of ST, FC, SC, LC, MU, DIN, E2000, LX.5, SMA, MTRJ, VF-45,MPO-MTP, etc. With different structure, there are types of hybrid adapter(Female to Female, Female to Male) and bare fiber adapters.
Fiber optic adapters normally comes with metal or plastic housings, there are types of ST, FC, SC, LC, MU, DIN, E2000, LX.5, SMA, MTRJ, VF-45,MPO-MTP, etc. With different structure, there are types of hybrid adapter(Female to Female, Female to Male) and bare fiber adapters.
Optical adapter (also called the flange) is a fiber optic connecting part on the activities of linking components. The complete series of products, including FC, SC, ST, LC, MTRJ,E2000, widely used in optical distribution frames (ODF), and optical fiber communications equipments, instruments. Performance is stable and reliable.
Application：
* Telecommunication
* CATV
* LAN & WAN
* Network
* Broadband
* FTTP
Features：
*Single mode and Multimode
*Zirconia sleeves or Phosphor bronze sleeves
* NTT standard compatible
* Available without flanges or with flange for duplex,
Saving panel space
* SC2 8Port high density for patch panel mount applications
* Meet JIS5974 and bellcore GR-326 standard
* Compliant with IEC874-14 & IEC874-19
* All parts compliant with ROHS
|
Parameter |
Unit |
LC, SC, FC, ST, E2000, MPO, MTP, Mu, MTRJ |
|||
|
SM |
MM |
||||
|
PC |
UPC |
APC |
PC |
||
|
Insertion Loss (Typical) |
dB |
≤0.2 |
≤0.2 |
≤0.2 |
≤0.2 |
|
Return Loss |
dB |
≥45 |
≥50 |
≥60 |
≥30 |
|
Exchangeability |
dB |
≤0.2 |
|||
|
Repeatability |
dB |
≤0.2 |
|||
|
Durability |
Time |
>1000 |
|||
|
Operating Temperature |
°C |
-40~75 |
|||
|
Storage Temperature |
°C |
-45~85 |
|||
