Based on an advanced formula, the plastic parts are made of injection-molded, high-strength engineering plastic ABS or PC by numerical control equipment; therefore effectively prevent products from aging caused by coldness, heat, oxygen and ultraviolet radiation. The strong housing and main components provide fire-resistant, waterproof, and quakeproof while protecting splices during pulling, compressing, and impacting, bending, tensioning, axial tensioning.
1.Description
Based on an advanced formula, the plastic parts are made of injection-molded, high-strength engineering plastic ABS or PC by numerical control equipment; therefore effectively prevent products from aging caused by coldness, heat, oxygen and ultraviolet radiation. The strong housing and main components provide fire-resistant, waterproof, and quakeproof while protecting splices during pulling, compressing, and impacting, bending, tensioning, axial tensioning.
2.Technical Index
|
Model No. |
SC-ATH120-01 |
Color |
Black |
|
Capacity |
120 cores |
Protection Level |
IP68 |
|
Material |
PC+ABS,ABS |
Inlet/outlet |
3+3 |
|
Dimension(MM) |
369*186*146 |
Screw mechanical |
|
|
Inlet cable port |
Ф14.5，Ф12，Ф9.5 |
Outlet cable port |
Ф14.5，Ф12，Ф9.5 |
3.features
1. Horizontal fiber splicing type
2. Total capacity of 24~144 cores, up to 6 disks
3. Elastic integral seal to ensure fastening
4, the house to provide fire, waterproof, shockproof splicing processing
5, working temperature :-40~+65℃
4.Applications
CATV system
Optical fiber communication
Testing equipment
FTTX
Fiber optic network convergence
Optical fiber access network
Fiber data transmission
Optical fiber video transmission
Fiber multimedia system
Fiber ethernet
Photoelectric conversion system
