Optic fiber clousure is applied in the junction and protecting of the fiber.It can be place with the aerial cable or buried in earth or put in the pipeline.The outer part and the fusing part of the clousure are made of the project plastic with the virtue .
1.Overview
Optic fiber clousure is applied in the junction and protecting of the fiber.It can be place with the aerial cable or buried in earth or put in the pipeline.The outer part and the fusing part of the clousure are made of the project plastic with the virtue .
2.Technical Index
|
Model No. |
SC-ATH144-01 |
Color |
Black |
|
Capacity |
144 cores |
Protection Level |
IP68 |
|
Material |
PC, PC+ABS,PP |
Inlet/outlet |
2+2 |
|
Dimension(MM) |
430*182*124 |
Screw mechanical |
|
|
Inlet cable port |
Ф21 |
Outlet cable port |
Ф21 |
3.Features
(1)Great mechnical performance.
(2)Great resisting aging performance.
(3)High airproof,dampproof and resisting,lightning strike performance.
(4)Can be place with the aerial cabal or buried in carth put in the pipeline.
(5)The in and out channels can be two to six.
This Installation Manual suits for the Fiber Optic Splice Closure (Hereafter abbreviated as FOSC), as the guidance of proper installation.The Scope of application is :aerial,underground,pipeline,handhole.The ambient temperature ranges from -40 to 65℃.
